Printer Model | BP420 | BP420E |
Printing Features |
Resolution | 203 DPI | 300 DPI |
Printing method | Thermal Transfer / Direct Thermal | Print Speed : 127 mm (5”)/s |
Max.print width | 108 mm (4.25”) | 104 mm (4.09”) |
Max.print length | 1778 mm (70”) | 889 mm (35”) |
Media |
Media type | Continuous, gap, black mark, fan-fold and punched hole |
Media width | 25.4-118mm (1.0”-4.6”) | thickness : 0.06~0.254 mm (2.36~10mil) |
Media core diameter | 25.4 ~ 76.2 mm (1 ”~ 3 ”) |
Label length | 10 - 1778 mm(0.39” ~ 70” ) | 10 ~ 889 mm(0.39” ~ 35” ) |
Label roll capacity | 127 mm (5“) OD (outside wound) |
Ribbon Capacity | Max.300m | Ribbon width: 110m |
Performance Features |
Processor | 32-bit CPU | |
Memory | 8MB Flash Memory/8MB SDRAM/Flash Can be expanded to Max. 4 GB |
Interface | Standard: USB TF card Optional: LAN/WIFI/Bluetooth/Serial |
Sensors | ①Gap sensor, ②Cover opening sensor, ③Black mark sensor, ④Ribbon sensor |
Fonts/Graphics/Symbologies |
Internal fonts | 8 alpha-numeric bitmap fonts, Windows fonts are downloadable from software. |
1D Barcode | Code 39, Code 93, Code 128UCC, Code 128,subsets A, B, C, Codabar, Interleaved 2 of 5,EAN-8,EAN-13, EAN-128, UPC-A, UPC-E, EAN and UPC2(5) digits add-on, MSI, PLESSEY, POSTNET, China POST, GS1 DataBar, Code 11 |
2D Barcode | PDF-417, Maxicode, DataMatrix, QR code, Aztec |
Rotation | 0°, 90°, 180°, 270° |
Emulsion | TSPL, EPL, ZPL, DPL |
Physical Features |
Dimension | 299 mm (D) x 235 mm (W) x 198.3 mm (H) |
Weight | 2.55kg |
Reliability |
Print head Life | 30 km |
Driver | Windows/Linux/Mac | SDK : Windows/Linux/iOS |
Power supply |
Input | AC 100-240V,1.8A, 50-60Hz | Output：DC 24V, 2.5A, 60W |
Environmental Conditions |
Operation Environment | 5 ~ 40°C(41~104°F), Humidity: 25 ~ 85% non-condensing |
Storage environment | -40 ~ 60°C（-40~140°F),Humidity:10 ~ 90% non-condensing |
Factory Options | ① Built-in Ethernet server (10/100 Mbps), ② RS-232C (2400-115200 bps) communication interface, ③Cutter, ④Peeling machine, ⑤Bluetooth module, ⑥WiFi module |
Dealer Options | ①External paper roll holder and 1”paper roll, ②Extension board for external paper roll holder |
